系列Series

LEV100/200

EV200

EV250

EV500

K61/81

型號

Type

LEV100(200)A4 ---

LEV100(200)A5 ---

LEV100(200)A6 ---

LEV100(200)H4 -- -

LEV100(200)H5 -- -

LEV100(200)H6 -- -

EV200AA- --

EV200AD---

EV200AJ-- -

EV200HA---

EV200HD---

EV200HJ---

EV250-1A

EV250-1B

EV250-2A

EV250-2B

EV250-5A

EV500-4A

EV500-4B

EV500-5A

EV500-5B

K61A- --

K61B---

K61C---

K81C---

安規認證

Agency Approval

——

SHAPE \* MERGEFORMAT

——

——

——

觸點形式

Contact Form

A=常開

H=常開＋輔助觸點

A=Normally Open

H=Normally Open with Aux. Contacts

——

4=無輔助觸點

5=輔助觸點

4=No Aux. Contacts

5=with Aux. Contacts

A=SPST-NO

B=SPST-NC

C=SPDT

額定工作電壓

Rated Operating Voltage

12-900 VDC

12-900 VDC

28-1800VDC

28-1800VDC

10KV/ K61

25KV/ K81

連續攜帶電流

Continuous(Carry) Current, Typical

500Amps @65℃

500Amps @85℃

400Amps

500Amps/6 minutes

600A@270VDC,85℃

1600A/10 seconds

6Amps@DC/60Hz

斷開電流@320VDC

Break Currents

2000Amps

2000Amps

2500Amps

3300Amps

——

典型/接觸電阻

Contact Resistance,

Typ./ Max.

0.2 MΩ @200A

0.2 MΩ @200A

0.0003Ω

0.0002Ω

0.05Ω / 0.5Ω

機械壽命

Mechanical Life

100,000 次

1,000,000次

——

——

——

輔助觸點接觸電流

Aux. Contact Current Max.

2A@30VDC

3A@125VAC

2A@30VDC

3A@125VAC

——

——

——

輔助觸點接觸電流

Aux. Contact Current, Min.

100mA@8V

100mA@8V

——

——

——

輔助觸點接觸電阻

 Aux. Contact Resistance Max.

0.417@30VDC

0.150@125VAC

0.417@30VDC

0.150@125VAC

——

——

——

絕緣電阻@500VDC

Insulation Resistance

100 MΩ

100 MΩ

100 MΩ

100 MΩ

——

溫度范圍

Operating Ambient

Temperature

-40℃ ～ ＋65℃

-40℃ ～ ＋85℃

-40℃ ～ ＋85℃

-40℃ ～ ＋85℃

-55℃ ～ ＋85℃

標稱重量

Weight, Typical

0.60

0.43

0.7 kg / 0.8 kg

1.53kg

——

線圈

數據

Coil

Operating

Voltage

標稱電壓

Coil Voltage

4=12VDC

5=24VDC

6=48VDC

A=9-36VDC

D=32-95VDC

J=48-95VDC

A=12VDC

B=24VDC

A=12VDC

B=24VDC

2=12VDC

3=26.5VDC

5=115VDC

電壓范圍

Voltage

(will operate)

9.6-13.2VDC

19.2-26.9VDC

38.4-52.8VDC

A=9-36VDC

D=32-95VDC

J=48-95VDC

——

——

——

電壓

Voltage Max.

15VDC

30VDC

60VDC

36VDC

95VDC

95VDC

——

——

——

拾起電壓

Pickup (close)

voltage Max.

9.6VDC

19.2VDC

38.4VDC

9VDC

32VDC

48VDC

-1A/B: 8.3/ 16.6VDC

-2A/B:  9/ 18VDC

-5A:    9VDC

9.9VDC

19.7VDC

8VDC

16VDC

80VDC

安裝方式

Mounting Terminals

底部/側面

Bottom/ Side

底部

Bottom

PC板

PC Board

連接方式

Terminal Options

螺栓/ 引出線

Male 10mm×M8 Threaded Terminals/ Wires

螺栓

Male 10mm×M8 Threaded Terminals

引出線，插針

Wires/ Pin Terminals
